PLUNGER PUMP DEMONSTRATION UNIT
Plunger Pump Demonstration Unit: MTFM-107
A motor-driven plunger pump, mounted on a stainless steel plinth with a water reservoir, pulsation damper and pipework for continuous circulation. The pump head, measuring tank, pulsation damper and the water reservoir are manufactured from clear acrylic for maximum visibility.
The pump outlet is connected to both a sprung loading valve and a needle valve to investigate different loading characteristics. A pressure relief valve protects the operator and the equipment. An additional valve can be used to isolate or include the pulsation damper, allowing the effect of damping to be investigated Electronic sensors measure the instantaneous cylinder pressure within the pump, the pump displacement and the cumulative flow over a period of time.
TECHNICAL SPECIFICATIONS:-
- Max flow rate: 0.725 l/m typical
- Max head: 4 bar
- Swept volume: 15 mm stroke x 32 mm diameter
- Pumping speed: Variable up to 60 strokes/min
- Motor power rating : 250 W
- Volume: 1.00 m3
- Gross weight: 120 kg
** Note: The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK ” keeps the right to modify the content in the product without prior notice.
