MEASUREMENT OF XD AND XQ OF THREE PHASE SYNCHRONOUS MACHINE
Measurement of XD and XQ of three Phase Synhronous Machine: MTEE-09
Measurement of XD and XQ of Three Phase Synchronous Machine is an exclusive product designed to demonstrate the operating principle and functioning of Three Phase Synchronous Generator.
This machine lab can change the mechanical energy to electrical energy. It helps students to analyze and calculate the significant parameters such as positive, negative and zero sequence impedance, direct and Quadrature axis reactance etc. to correctly construct Three Phase Synchronous Generator.
It includes separate terminals for rheostat and three point starter provided on the control set-up so that students can make connections by themselves with adequate protections.
FEATURES:-
- Electrical Loading Arrangement
- Flexible Shaft Coupling Arrangement
- Provided with Digital Tachometer
- Machine with Class “B” Insulation
- Heavy Duty Base/Channel
- Equipped with supply indication lamps
- Terminals provided to use the optional externally
- Equipped with supply indication lamps
- Designed by considering all the safety standards
- Diagrammatic representation for the ease of connections
- Exclusive and Compact Design
TECHNICAL SPECIFICATIONS:-
- Mains Supply : Three Phase, 415V±10 %, 50Hz
- Rating : 2HP
- Voltage Rating : 220V ±10 %
- Speed : 1500 RPM ±5 %
- Voltage Rating : 415V
- Rating : 3HP
- Speed : 1500 RPM
- Excitation Voltage : 120V ±10 %
- Digital Meters used
- DC Voltmeter : 300V
- DC Ammeter : 10A
- AC Voltmeter : 450V (2 no’s)
- AC Ammeter : 5A & 10A (1 each)
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK“ keeps the right to modify the content in the product without prior notice.
