ROTARY VACUUM PUMPS
ROTARY VACUUM PUMPS : JEQ-10
Rotary Vacuum Pumps is mounted on heavy steel base, oil sealed, heavy duty electric motor, v-belt driven at speed up to 400 RPM, components high grade cast iron are the main features. Supplied in single or double stage models creating maximum vacuum of 0.01 mm of Hg column or 0.001 mm of Hg. Column respectively. It works on 220V AC 50Hz single phase. Provided with belt guard, non return valve and vacuum gauge.
| Capacity | Motor |
| 25 lit./mt. | 0.25 hp |
| 45 lit./mt. | 0.25 hp |
| 75 lit./mt. | 0.25 hp |
| 100 lit./mt. | 0.50 hp |
| 150 lit./mt. | 0.50 hp |
| 200 lit./mt. | 1.00 hp |
Optional:-
- Moisture trap.
- Non return Valve.
- Air blast.
Note : Ask for oil free vacuum pumps.
MODELS: AVAILABLE IN SINGLE STAGE AND DOUBLE STAGE
