SINGLE AND THREE PHASE INDUCTIVE LOAD
Single and three Phase Inductive Load: MTEE-28A
Single and Three Phase Inductive Load is suitable for loading Single Phase and Three Phase supplies and generators. It consist three variable inductive coils. Two terminals for each phase are given which are externally accessible through an inbuilt star delta switch.
All inductive coils are electrically isolated and separate terminals for each phase are provided on panel through a star/delta switch so that the students can connect as a star or delta load for three-phase circuits.
A movable handle is used to change the inductance of the load. Students can connect the load to experiment circuits using specially designed patch cords on the enclosed front panel. The load is mounted on a trolley to provide facility of easy movement in laboratories.
FEATURES:-
- Compatible for Single and Three Phase Operation
- Suitable for both static & rotating machines
- Totally independent banks to allows star or delta configuration by inbuilt star delta switch
- Load variation can be obtained by movable handle
- Heavy duty castor wheel for easy movement
- Equipped with Supply Indication Lamps
- High class meter being used
- Exclusive and rugged designed panel
- Designed by considering all the safety precautions
TECHNICAL SPECIFICATIONS:-
- Single Phase Operation
- Voltage : 230V AC ±10%, 50Hz
- Current : 15A
- Power : 3.5 KVAR
- Three Phase Star Operation
- Voltage : 415V AC ±10%, 50Hz
- Current : 5A (per Phase)
- Power : 3.5 KVAR
- Three Phase Delta Operation
- Voltage : 415V AC ±10%, 50Hz
- Current : 15A (per Phase)
- Power : 10 KVAR
- Star/Delta Switch : 415V, 25A
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK“ keeps the right to modify the content in the product without prior notice.
