PRECISE DATA ACQUISITION
Precise Data Acquisition: MTDA-06
Increasing complexities in electronic systems have resulted in the need of the instruments capable of measuring a wide range of input signals at fast sampling speeds over longer periods of time. Perfected over years of continuous innovations, precise data acquisition is a unique solution to meeting the most stringent measurement requirements. Built to endure the harshest measuring environments, precise data acquisition offers the superior performance and high reliability expected of a waveform measuring instrument.
FEATURES:-
- Flexibility: Choose and combine up to 19 types of plug-in module to fit a variety of measuring applications. Simultaneously capture and display data from electrical and physical sensor signals.
- Reliability: Precisely measure signals at high resolution and secure data in the harshest environments with superior isolation technology.
- Functionality: Combining the signal fidelity of an oscilloscope and data recording of a recorder, data can be thoroughly analyzed in fine detail or viewed as a trend over
TECHNICAL SPECIFICATIONS:-
- Rated power supply voltage 100 to 120 VAC/220 to 240 VAC (automatic switching)
- Rated power supply frequency 50/60 Hz
- Maximum power consumption 200 VA
- Withstand voltage 1500 V AC between power supply and earth for 1 minute
- Insulation resistance 10 MΩ or higher at 500 V DC between power supply and earth
- External dimensions Approx. 355 mm (W) ×259 mm (H)× 180 mm (D), excluding handle and other projections
- Operating temperature range 5 to 40˚C
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” keeps the right to modify the content in the product without prior notice.
