HOME ELECTRICAL WIRING TRAINING SYSTEM
Home Electrical Wiring Training System: MTEE-41
Home Electrical Wiring Training System is a product which is helpful for students to get familiar with home wiring circuits. This product provides a realistic training environment which is essential for every electrical engineering student and also for apprentice electrician.
It consists of Single Phase Energy Meter, MCB, Controlling Switches, Tube Light with Choke, Regulated Switch, Ceiling Fan, etc. Good quality safe terminals and sockets are provided at appropriate places on board for power supply and load connections.
FEATURES:-
- Equipped with Multifunction meters with KWH display
- Complete practical learning for wiring in Houses
- Test points are provided to measure voltage at different points
- Provided with house hold appliances like fan
- Designed by considering all the Safety Standards
- Diagrammatic representation for the ease of connections
TECHNICAL SPECIFICATIONS:-
- Mains Supply : 230V AC ±10%, 50Hz
- Energy Meter Specifications
- Meter Constant : 1600 impulses /kWh
- Display Counter : 100 impulses /kWh
- Single Phase MCB : 6A
- Load specifications
- Tube Light : 20W, 220-240V
- Ceiling Fan : 50W, 220-240V
- Maximum Load Current : 4A
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK“ keeps the right to modify the content in the product without prior notice.
