EXPERIMENTATION OF OP-AMP CHARACTERISTICS

Experimentation of OP-AMP Characteristics: MTBE-09

Experimentation op-amp characteristics the basic functions and characteristics of operational amplifiers the pumps are use in mathematical operations such as addition, subtraction, integration, differentiation and so on. However, an ideal operational amplifier is an extremely versatile circuit element, with many applications beyond mathematical operations and to understand and perform those applications, it is necessary to have better understanding of its basic operation has been divided into different blocks for the ease of user to understand the various operations of operational amplifier. A Function Generator, generating Sine wave, Square wave and triangular wave, and two variable DC Supplies are provided on board.

FEATURES:-

Self-contained easy to operate TechBook
On board Function Generator
Functional blocks indicated on board mimic
Built in DC Power Supplies
Online Product Tutorial
Compact size

Description

SCOPE OF LEARNING:-

Observe Open-Loop Gain as a function of frequency Measure CMRR
Op-amp gain in voltage series feedback configuration Observer the functioning of voltage follower i.e. buffer
Op-amp gain in voltage shunt feedback configuration
Op-amp as a differential amplifier and observe its output Observe Op-amp as I-V Converter
Observe Op-amp as V-I Converter
Observe Op-amp as Inverting Summer
Observe Op-amp as Inverting Average
Observe Op-amp as Inverting Scalar
Observe Op-amp as a non-inverting Average
Observe Op-amp as non-inverting Summer
Observe Op-amp as an Integrator
Observe Op-amp as Differentiator

TECHNICAL SPECIFICATIONS:-

Function Generator
Outputs: Sine, Square and Triangle
Frequency: 10 Hz, 100 KHz
DC Power Supplies: 0 – 5 V variable, 2 Nos.
Test Points: 28 no’s
Power Supply: 110-220 V ±10%, 50/60 Hz
Power Consumption: 4 VA approximately
Operating Conditions: 0-40 C, 80% RH

** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” keeps the right to modify the content in the product without prior notice.
