Description
SCOPE OF LEARNING:-
- Operation of all Logic gates
- Study of Flip-flops
- Crystal oscillator
- Johnson Counter
- Shift Register
- 8 to 3 line Encoder
- Pulse Stretcher Circuit
- CMOS-TTL Interfacing
- Binary addition Half adder, Full adder, 2 bit Binary parallel adder
- Binary subtraction
- Binary to Gray code conversion
- Gray code to Binary conversion
- Binary to Excess-3 code conversion
- 4 bit Binary up-down counter
- Multiplexer and De-multiplexer Circuits
TECHNICAL SPECIFICATIONS:-
- Size of Breadboard: 172.5 mm x 128.5 mm
- Tie Points on Breadboard: 1685 no’s (solder less)
- DC Power Supplies: +5V, 1A; -5V, 500 mA (fixed)
- +3V to +15V, 500 mA (variable)
- -3V to -15V, 500 mA (variable)
- Pulsar Generator: 1Hz to 1MHz in 6 steps (Variable in between the steps)
- Amplitude : +3V to +15V (CMOS), 5V (TTL)
- Duty Cycle: 50 %, output
- Pulsar Switches: 2 no’s (Push to ‘On’)
- Data Switches: 16 no’s (Toggle switches) (TTL/CMOSoutput)
- Bicolor LED Display : 16 no’s (TTL/CMOS input)
- BCD to 7 Segment Display : 2 no’s
- Logic Probe: Logic level indicator (H/L)for
- Mains Supply: 110-220V ± 10%, 50/60Hz
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” keeps the right to modify the content in the product without prior notice.
