DIELECTRIC CONSTANT MEASUREMENT
Dielectric Constant Measurement: MTBE-15
Dielectric Constant Measurement is designed to measure Dielectric Constant of different solid materials like Teflon, Glass, Bakelite, etc. A dielectric substance is the electrically insulating material. An effective dielectric typically contains polar molecules that reorient in external electric field. Such materials when placed between the plates of a capacitor it increases the polarization and the value of the capacitance. The dielectric constant is the ratio of electrical conductivity with dielectric material and without dielectric material. Uses this relation for calculating dielectric constant with the help of inbuilt RF signal generator and LCD. Dielectric Constant Measurement is an ideal platform to enhance education, training, skills & development among our young minds.
FEATURES:-
- Very easy to operate
- Provided with in-built Variable and Test capacitor
- Variable capacitor with high accuracy measurement
- LCD display
SCOPE OF LEARNING
- Measurement of Dielectric Constant of Different Materials
TECHNICAL SPECIFICATIONS:-
- Main Supply : 230V ±10%, 50Hz
- Display : LCD
- Variable Capacitor : 20-290pF
- Test Sample : Glass, Bakelite and Teflon
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” Keeps the right to modify the content in the product without prior notice.
