DIGITAL C.B.R. APPARATUS

Digital C.B.R. Apparatus: MTST-03

The Machine is composed of a robust and compact two column frame with adjustable upper crossbeam driven by an electromechanical ram with a maximum capacity of 50 kN and a data acquisition and processing system.
The Machine is designed to load the penetration piston into the soil sample at a constant rate to measure the applied load and piston penetration at predetermined intervals. The ram speed can be set between 0.5 mm/min to 5 mm/min by using the TCM digital readout unit. The same machine Rapid adjustment of the platen is also provided by up and down buttons which are located on the front panel of the machine.

Features:-

Automatically calculates flow and stability values
240*120 pixel blue-white graphic LCD display.
High resolution 65.000 points.
Backlight function.
Capability of contrast calibration by light.
21 key touch membrane keyboards.
Two analogical and two digital channels, use for load cell or pressure transducer MTC.
Standalone full automatic testing capacity.
Can make manual tests if requested.
A sample type and dimension can be entered respect to the standards,
Load-Time, Tensile-Time, Test Results and Sample reports observable and printable.
Comes with Connection cable and software.
Large permanent memory up to 256 test results.
Language select, English – Turkish.

Category: Soil Testing Equipments

Description
Product Enquiry

Description

Technical Specification:-

Capacity 50 kN
Platen Speed 0.625 to 5 mm/min.
Power 370 W
Large graphic touch screen display 240 X 128 pixel,
Effective resolution 16 bit ,
Effective sampling rate 40 Hz ,
Communication port

Accessories:-

Plated steel
Extension collar
Perforated base plate

** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” keeps the right to modify the content in the product without prior notice.
