Marshall Stability Test Apparatus Digital

Marshall Stability Test Apparatus Digital: MTBA-20A

It may be defined as the testing frame is the same as but the load is measured by an electric cell with high precision strain transducers; the flow is measured by displacement transducer 50 mm stroke and ±0.1% linearity. The Datatronic 5 channels digital display unit with microprocessor measures and displays at the same time the stability in kN and the flow in mm with pick hold features with the possibility to transfer them to a PC and a printer through a RS232 port, with stability mould, 230 V, 1 ph, 50 Hz, 900 W.

Features:-

Load Ring included
LVDT included
Breaking Head included
Tensile Splitting Device available
Density – Voids Analysis
Stability – Flow Tests
The Marshall Stability tester is equipped with one S shape load cell and double displacement sensors.
Peak value is automatically preserved.
The principal axis automatically descends after printing.
With printer
Powder coating

Category: Bitumen and Asphalt Testing Equipment

Description
Product Enquiry

Description

Technical Specification:-

Capacity: 0-50KN precision: 1%
Resolution: 0.1KN, 0.01KN
Twin displacement structure, displacement resolution: 0.01mm
Environment temperature: -10 degree -40degree
Test speed 50.8mm/minute
Supplied with one breaking head, diameter 101.6mm

Accessories:-

Automatic Marshall Compactor
Manual Marshall Compactor
Marshall Mould
150mm Breaking Head
100mm Breaking Head
100mm Tensile Splitting Device

** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK “keeps the right to modify the content in the product without prior notice.
